ASROCK B560M PRO4 10TH AND 11TH GEN MICRO ATX MOTHERBOARD…G-Express BD

৳ 11,800

Key Features

Supports 10th and 11th Gen Intel Core Processors
Supports DDR4 4800MHz (OC)
Graphics Output: HDMI, DisplayPort
Form Factor: Micro ATX
Stock:In Stock
Brand:ASRock
Model:B560M Pro4

Categories: ASRock, Motherboard

Description
Reviews (0)

SPECIFICATION

MOTHERBOARD
Supported CPU	Supports 10th Gen Intel Core Processors and 11th Gen Intel Core Processors (LGA1200) Digi Power design 8 Power Phase design Supports Intel Turbo Boost Max 3.0 Technology
Chipset	Intel B560
Memory	Dual-Channel DDR4 Memory Technology 4 x DDR4 DIMM Slots 11th Gen Intel Core Processors support DDR4 non-ECC, un-buffered memory up to 4800+(OC) 10th Gen Intel Core Processors support DDR4 non-ECC, un-buffered memory up to 4600+(OC) – Supports ECC UDIMM memory modules (operate in non-ECC mode) Max. the capacity of system memory: 128GB Supports Intel Extreme Memory Profile (XMP) 2.0
Graphics	11th Gen Intel Core Processors support Intel Xe Graphics Architecture (Gen 12). 10th Gen Intel Core Processors support Gen 9 Graphics – Graphics, Media & Compute: Microsoft DirectX 12, OpenGL 4.5, Intel Built-In Visuals, Intel Quick Sync Video, Hybrid / Switchable Graphics, OpenCL 2.1 Display & Content Security: Rec. 2020 (Wide Color Gamut), Microsoft PlayReady 3.0, UHD/HDR Blu-ray Disc Dual graphics output: Support HDMI and DisplayPort 1.4 ports by independent display controllers Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096×2160) @ 60Hz Supports DisplayPort 1.4 with max. resolution up to 4K x 2K (4096×2304) @ 60Hz Supports Auto Lip Sync, Deep Color (12bpc), xvYCC, and HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant HDMI monitor is required) Supports HDCP 2.3 with HDMI 2.0 and DisplayPort 1.4 Ports Supports 4K Ultra HD (UHD) playback with HDMI 2.0 and DisplayPort 1.4 Ports
Slots	11th Gen Intel Core Processors 2 x PCI Express x16 Slots (PCIE1/PCIE3: single at Gen4x16 (PCIE1); dual at Gen4x16 (PCIE1) / Gen3x4 (PCIE3)) 10th Gen Intel Core Processors 2 x PCI Express x16 Slots (PCIE1/PCIE3: single at Gen3x16 (PCIE1); dual at Gen3x16 (PCIE1) / Gen3x4 (PCIE3)) 1 x PCI Express 3.0 x1 Slot Supports AMD Quad CrossFireX and CrossFireX 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVi (Integrated WiFi/BT)
Supported Storage	6 x SATA3 6.0 Gb/s Connectors, support Intel Rapid Storage Technology 18, NCQ, AHCI, and Hot Plug 1 x Hyper M.2 Socket (M2_1), supports M Key type 2242/2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (Socket M2_1 works with 11th Gen Intel Core processors only) 1 x Ultra M.2 Socket (M2_2), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s
LAN	Gigabit LAN 10/100/1000 Mb/s Giga PHY Intel I219V Supports Wake-On-LAN Supports Lightning/ESD Protection Supports Energy Efficient Ethernet 802.3az Supports PXE
Audio	7.1 CH HD Audio (Realtek ALC897 Audio Codec) Supports Surge Protection Nahimic Audio
Internal I/O Ports	SPI TPM Header Chassis Intrusion and Speaker Header 2 x RGB LED Headers 2 x Addressable LED Headers 1 x CPU Fan Connector (4-pin) 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control) 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control) 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) 1 x Front Panel Audio Connector 1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt 4 AIC Card) 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) 1 x Front Panel Type C USB 3.2 Gen1 Header (Supports ESD Protection)
External I/O Ports	3 x Antenna Mounting Points 1 x PS/2 Mouse/Keyboard Port 1 x HDMI Port 1 x DisplayPort 1.4 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) 2 x USB 2.0 Ports (Supports ESD Protection) 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone
DIMENSIONS	9.6-in x 9.6-in, 24.4 cm x 24.4 cm
Form Factor	Micro ATX Form Factor
BIOS	128Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 6.0 Compliant wake-up events SMBIOS 2.7 Support CPU Core/Cache, GT, DRAM, VPPM, VCCIN AUX, VCCSA, VCCIO Multi-adjustment
Warranty	3 Years Warranty

DESCRIPTION

ASRock B560M Pro4 Micro ATX Motherboard in Bangladesh

The ASRock B560M Pro4 delivers unbeatable durability and stunning aesthetics. Built with the most demanding specs and features, the Steel Legend aims at both daily users and seasoned PC enthusiasts. Utilize a strong array of materials and compo. The durability and protection systems the B560M offers include a full Coverage M.2 heatsink which improves heat dissipation, also for durability there are Solid Steel PCIe Slots that provide support for PCIe components and prevent shearing. Get super fast and reliable connections with the new Dual USB 3.2 Gen2 ports to support your next-generation devices.

PCIe 4.0

ASRock B560M Pro4 motherboard is capable of accommodating multiple M.2 storage devices, ASRock B560M Pro4 one among which may even support next-generation PCI Express 4.0 M.2 SSD, ASRock B560M Pro4 ‘s capable of performing twice the speed compared to the previous 3rd generation, giving a lightning-fast data transferring experience

Nahimic Audio

ASRock B560M Pro4 Whether you’re using headphones, a headset, external or internal speakers, via USB, Wi-Fi, analog output, or maybe HDMI, Nahimic Audio offers you the foremost engaging listening experience, vibrant and rich with details.
